PS-VBL Series | Brushless Fully Automatic Electric Screwdriver – Vacuum Type
Model
PS10VBL, PS11VBL, PS20VBL, PS21VBL, PS30VBL, PS31VBL, PS32VBL, PS33VBL, PS41VBL, PS42VBL, PS45VBL, PS51VBL
Application
Automation Industry Tools
Function
Vacuum Type
Product Type
Wrench Screwdriver Type
Torque Range
0.5–280 kgf·cm / 0.05–28.0 Nm
| Model | No-Load Speed | Weight | Overall Length | Diameter | Torque Range | Power Supply | Torque | CPK Value (Compliant with ISO 5393) | Fastening Capacity | Accessories | |
| r.p.m. | g | mm | mm | Kgf-cm | V(DC) | % | Machine Screw | Self-Tapping Screw | Bit Size 1/4” |
||
| PS10VBL | 300 | 305 | 207 | 36 | 0.2-2.0 | 12 | ±3 | 1.67 | M1.0-M2.2 | M0.9-M1.7 | #0 |
| PS11VBL | 1000 | 305 | 207 | 36 | 0.2-2.0 | 12 | ±3 | 1.67 | M1.0-M2.2 | M0.9-M1.7 | #0 |
| PS20VBL | 300 | 305 | 207 | 36 | 0.5-5.0 | 12 | ±3 | 1.67 | M1.4-M2.8 | M1.1-M2.3 | #0 |
| PS21VBL | 1000 | 305 | 207 | 36 | 0.5-5.0 | 12 | ±3 | 1.67 | M1.4-M2.8 | M1.1-M2.3 | #0 |
| PS30VBL | 300 | 305 | 207 | 36 | 1.0-10 | 12 | ±3 | 1.67 | M1.7-M3.5 | M1.4-M2.9 | #0 |
| PS31VBL | 1000 | 355 | 207 | 36 | 1.0-10 | 12 | ±3 | 1.67 | M1.7-M3.5 | M1.4-M2.9 | #0 |
| PS32VBL | 1400 | 355 | 207 | 36 | 1.0-10 | 12 | ±3 | 1.67 | M1.7-M3.5 | M1.4-M2.9 | #0 |
| PS33VBL | 650 | 355 | 207 | 36 | 1.0-10 | 12 | ±3 | 1.67 | M1.7-M3.5 | M1.4-M2.9 | #0 |
| PS41VBL | 1000 | 355 | 207 | 36 | 3.0-17 | 12 | ±3 | 1.67 | M2.5-M4.3 | M2.0-M3.4 | #2 |
| PS42VBL | 1400 | 355 | 207 | 36 | 3.0-17 | 12 | ±3 | 1.67 | M2.5-M4.3 | M2.0-M3.4 | #2 |
| PS45VBL | 450 | 355 | 207 | 36 | 5.0-25 | 12 | ±3 | 1.67 | M2.8-M4.8 | M2.3-M3.8 | #2 |
| PS51VBL | 1000 | 355 | 207 | 36 | 5.0-30 | 12 | ±3 | 1.67 | M2.8-M5.0 | M2.3-M4.1 | #2 |
- High-Tech Brushless Motor – Energy-Saving & Environmentally Friendly
The high-tech brushless motor features spark-free operation, no carbon brush contamination, and no need for carbon brush replacement, resulting in a significantly longer service life compared to conventional brushed tools. The motor is also equipped with an automatic shut-off function that stops operation when the preset torque value is reached. - Patented Clutch System
A special structure combined with a patented clutch design delivers low noise, low vibration, and high precision, meeting stringent quality and performance requirements. - Externally Adjustable Torque
Allows users to quickly and easily adjust torque settings, improving operational efficiency and convenience. - Low Reaction Force
Ergonomically designed to enhance operator safety, protect wrists, reduce occupational injuries, and minimize hand strain caused by reaction force. - Non-Contact Switch Design
The trigger-activated non-contact switch provides high torque repeatability and precision, while ensuring safer operation. - Dual Reverse Button Design
The reverse switch features a modular design integrated with the power cable terminal and a non-contact switching mechanism, reducing the limitations of traditional contact-type switches and minimizing the risk of sparking. This design improves operator safety, ease of maintenance, lower failure rates, and extended tool lifespan. - New Vacuum Pick-Up Design
No external vacuum tube is required, offering a compact, impact-resistant, drop-resistant, and highly durable design. The tool incorporates the latest built-in vacuum pick-up technology, ensuring efficient operation without restricting workspace or movement. - Z-Type Automatic Screw Feeder
The Z-type screw feeding system delivers one screw at a time with zero errors. An integrated alignment guide plate ensures accurate positioning and precise fastening.
Brushed Motor vs. Brushless Motor — Simple Comparison
| Brushed Motor | Brushless Motor | |
| Control | Simple | Complex |
| Operating Temperature | Poor high-temperature resistance | High-temperature resistant |
| Efficiency | Low | High |
| Carbon Brushes | Requires regular cleaning / replacement | No carbon brushes |
| Maintenance | Regular maintenance required | Maintenance-free |
| Motor Size | Large | Compact |
| Weight | Heavy | Lightweight |
| Service Life | Short | Long |
| Motor Temperature Rise | High | Low |
| Torque Output | Low | High |
| Noise Level | High | Low |
| Sparking | Present | None |
Tool Operation Method
| Right-hand operation | Left-hand operation | ||
| Forward rotation / Tighten screw | Reverse rotation / Loosen screw | Forward rotation / Tighten screw | Reverse rotation / Loosen screw |
 |
 |
 |
 |
Product Diagram
Tighten screw (forward rotation) → Press the side (elongated) switch
Loosen screw (reverse rotation) → Press the center (round) switch
Please refer to the video.
Video Operation Steps:
- Starting at 0.05 seconds, perform Loosen (reverse rotation) → Tighten (forward rotation), repeating the action four times.
- At 0.17 seconds, switch to another screw, then perform Tighten (forward rotation) → Loosen (reverse rotation), repeating the action five times.
Additional Notes: Differences Between PS-VB Series and PS-VBL Series
- The PS-SBL series is an enhanced version, offering higher motor power and greater torque stability.
- The power supply unit features a larger and thicker housing, providing superior voltage regulation and stability.
