R-PBP Series | Pistol Grip Air Screwdriver (Push-to-Start or Push + Trigger Start)
R-PBP Series | Pistol Grip Air Screwdriver (Push-to-Start or Push + Trigger Start)

R-PBP Series | Pistol Grip Air Screwdriver (Push-to-Start or Push + Trigger Start)

Model

R35PBP,R38PBP,R41PBP,R47PBP,R48PBP,R50PBP,R55PBP,R60PBP,R65PBP,R68PBP

Applications

Assembly Line Tools

Product Inquiry
■ Ultra-Lightweight Innovative Grip and Award-Winning Design

Utilizes advanced materials to reduce handle weight by 25% to 44%, seamlessly blending professional aesthetics with human factors engineering—proud winner of the 2002 Osaka Good Tools Award.

■ Patented Staggered-Track Clutch and High-Power Motor

Delivers high-precision torque control via a patented staggered-track clutch system, combined with a patented motor design that boosts power output by 30% while minimizing vibration and noise.

■ 360° All-Directional Exhaust and Dual Air-Inlet

Features 360° all-directional exhaust alongside top and bottom air-inlet options, paired with an ergonomic design to provide lightweight operation and a comfortable grip across all production environments.

■ Pioneering Trigger-Lock Function and Color Management

Introduces a first-of-its-kind trigger-lock mechanism to prevent screw surface damage, alongside an optional color-coded torque management system to enhance assembly line quality control and operation safety.

■ Two Actuation Modes
Mode 1: Direct Push-to-Start (Trigger Locked).
               Engage the trigger lock for direct push-to-start operation.
Mode 2: Safety Interlock Start (Mistake-Proofing).
              Requires both trigger activation and tool engagement to prevent bit slippage and screw head damage; this safety
              mechanism may add approximately 1 second to the start-up time.
              [Note: The most common operation is pushing the tool down before pressing the trigger.]
Model Speed Weight Length Diameter Air
Pressure		 Min Air
Hose Bore		 Air
Consumption		 Torque
Range		 Standard
Deviation		 Fastening Capacity
rpm g mm mm kg/cm² mm m³/min kgf-cm % Machine
Screw		 Tapping
Screw
R35PBP 2200 640 180 33 6.0 5.0 0.28 3-20 ± 3 M2.5-M4.5 M2.0-M3.5
R38PBP 1800 640 180 33 6.0 5.0 0.28 3-25 ± 3 M2.5-M4.8 M2.0-M3.8
R41PBP 1000 640 180 33 6.0 5.0 0.28 5-35 ± 3 M2.8-M5.0 M2.3-M4.0
R47PBP 550 640 180 33 6.0 5.0 0.28 10-50 ± 3 M3.5-M6.0 M2.9-M4.8
R48PBP 1700 980 215 39 6.0 8.0 0.55 7-50 ± 3 M3.2-M6.0 M2.6-M4.8
R50PBP 1400 980 215 39 6.0 8.0 0.55 10-60 ± 3 M3.5-M6.2 M2.9-M5.0
R55PBP 1000 980 215 39 6.0 8.0 0.55 12-75 ± 3 M3.8-M6.8 M3.0-M5.5
R60PBP 550 980 215 39 6.0 8.0 0.55 30-110 ± 3 M5.0-M7.7 M4.1-M6.2
R65PBP 300 1100 215 39 6.0 8.0 0.55 30-180 ± 3 M5.0-M9.2 M4.1-M7.1
R68PBP 250 1250 215 39 6.0 8.0 0.55 50-280 ± 3 M6.0-M10.8 M4.8-M8.6
▲ Tool length does not include the air inlet fitting. Specifications are subject to change without prior notice.
★ 【Customization】Custom specifications are available based on customer requirements. Please contact us for more details.
★ 【Note】Torque values are for reference only. Actual performance may vary depending on operating conditions and environment.
★ 【Note】To ensure component durability and extend tool lifespan, it is recommended that the working torque during use does not exceed 70% of the tool’s maximum torque capacity. Continuous operation at the maximum torque may accelerate component wear and shorten the overall service life of the tool. This guideline can also serve as an important reference when selecting the appropriate model.
