T-PB Series | Push Start Type Air Screwdriver
Model
T10PB,T20PB,T30PB,T35PB,T38PB,T40PB,T45PB,T48PB,T50PB,T55PB,T60PB,T65PB,T68PB
Application
Assembly Line Tools
■ Quick-Change Push-Down Sleeve
Allows users to rapidly change bits by simply pressing down the sleeve, ensuring fast and convenient operation.
■ Anti-Slip Ergonomic Grip
Features specialized non-slip materials for a comfortable grip, eliminating fatigue during long-term use while delivering a professional aesthetic.
■ Patented Staggered-Track Clutch System
Precisely controls torque deviation and adapts effortlessly to a wide variety of operational requirements.
■ Wide Torque Range with Patented Technology
Replaces multiple tools with an ultra-wide torque capacity, while extending motor vane lifespan and boosting overall efficiency.
| Model | Speed | Weight | Length | Diameter | Air Pressure |
Min Air Hose Bore |
Air Consumption |
Torque Range |
Standard Deviation |
Fastening Capacity | |
| rpm | g | mm | mm | kg/cm² | mm | m³/min | kgf-cm | % | Machine Screw |
Tapping Screw |
|
| T10PB | 1000 | 500 | 180 | 29 | 6.0 | 5.0 | 0.20 | 0.5-2 | ± 3 | M1.4-M2.2 | M1.1-M1.7 |
| T20PB | 1000 | 500 | 180 | 29 | 6.0 | 5.0 | 0.20 | 1-8 | ± 3 | M1.7-M3.4 | M1.4-M2.7 |
| T30PB | 1800 | 500 | 180 | 29 | 6.0 | 5.0 | 0.28 | 3-17 | ± 3 | M2.5-M4.3 | M2.0-M3.4 |
| T35PB | 2200 | 500 | 180 | 29 | 6.0 | 5.0 | 0.28 | 3-20 | ± 3 | M2.5-M4.5 | M2.0-M3.5 |
| T38PB | 1800 | 500 | 180 | 29 | 6.0 | 5.0 | 0.28 | 3-25 | ± 3 | M2.5-M4.8 | M2.0-M3.8 |
| T40PB | 1000 | 500 | 180 | 29 | 6.0 | 5.0 | 0.28 | 5-30 | ± 3 | M2.8-M5.0 | M2.3-M4.1 |
| T45PB | 800 | 500 | 180 | 29 | 6.0 | 5.0 | 0.30 | 8-40 | ± 3 | M3.4-M5.6 | M2.7-M4.5 |
| T48PB | 1700 | 825 | 220 | 37 | 6.0 | 8.0 | 0.55 | 5-45 | ± 3 | M2.8-M5.8 | M2.3-M4.5 |
| T50PB | 1400 | 825 | 220 | 37 | 6.0 | 8.0 | 0.55 | 7-50 | ± 3 | M3.2-M6.0 | M2.6-M4.8 |
| T55PB | 1000 | 825 | 220 | 37 | 6.0 | 8.0 | 0.55 | 7-65 | ± 3 | M3.2-M6.5 | M2.6-M5.2 |
| T60PB | 550 | 825 | 220 | 37 | 6.0 | 8.0 | 0.55 | 15-95 | ± 3 | M4.0-M7.2 | M3.3-M6.0 |
| T65PB | 330 | 920 | 220 | 37 | 6.0 | 8.0 | 0.55 | 30-180 | ± 3 | M5.0-M9.2 | M4.1-M7.1 |
| T68PB | 250 | 920 | 220 | 37 | 6.0 | 8.0 | 0.55 | 50-280 | ± 3 | M6.0-M10.8 | M4.8-M8.6 |
＊ Tool length does not include the air inlet fitting.
▲ Specifications are subject to change without prior notice.
★ 【Customization】Custom specifications are available based on customer requirements. Please contact us for more details.
★ 【Note】Torque values are for reference only. Actual performance may vary depending on operating conditions and environment.
★ 【Note】To ensure component durability and extend tool lifespan, it is recommended that the working torque during use does not exceed 70% of the tool’s maximum torque capacity. Continuous operation at the maximum torque may accelerate component wear and shorten the overall service life of the tool. This guideline can also serve as an important reference when selecting the appropriate model.
● Output Drive
| 1/4" Hex | 5mm | 1/4" Square (FOR 10~45 type) |
3/8" Square (FOR 48~68 type) |
| PB | PA | PBS | PBS |
