A-ABF Series | Angle Type Oil-Free Low-Reaction Air Screwdriver
Model
A8212ABF,A8362ABF,A8392ABF,A8412ABF,A8462ABF,A8492ABF,A8512ABF,A8562ABF,A8612ABF,A8662ABF,A8692ABF
Application
Aerospace Industry Tools, Assembly Line Tools
■ Quiet, Stable, and Reduced Reaction Force
Ensures quieter and more stable operation while reducing reaction force by 20% for superior control.
■ Energy-Efficient Evolution
Delivers an evolution in performance with lower power consumption and enhanced operational efficiency.
■ Intuitive External Torque Adjustment
Features an external torque adjustment system, making setting modifications simpler and more intuitive for the operator.
■ Advanced Non-Slip Ergonomic Grip
Equipped with an all-new non-slip grip that is both comfortable and breathable, ensuring more secure and confident handling.
| Model | Speed | Weight | Length | Diameter | Noise | Air Pressure |
Min Air Hose Bore |
Air Consumption |
Torque Range |
Standard Deviation |
Fastening Capacity | |
| rpm | g | mm | mm | ±dBA | kg/cm² | mm | L/s | Nm | % | Machine Screw |
Tapping Screw |
|
| A8212ABF | 1000 | 800 | 280 | 40 | 67 | 6.0 | 5.0 | 4.6 | 0.1-1.2 | ± 2 | M1.7-M3.7 | M1.5-M3.1 |
| A8362ABF | 2200 | 800 | 280 | 40 | 67 | 6.0 | 5.0 | 4.6 | 0.5-2.5 | ± 2 | M2.2-M4.5 | M1.7-M3.5 |
| A8392ABF | 1800 | 800 | 280 | 40 | 67 | 6.0 | 5.0 | 4.6 | 0.5-3.0 | ± 2 | M2.2-M4.7 | M1.7-M3.8 |
| A8412ABF | 1000 | 810 | 280 | 40 | 67 | 6.0 | 5.0 | 4.6 | 0.5-4.0 | ± 2 | M2.8-M5.0 | M2.2-M4.0 |
| A8462ABF | 800 | 810 | 280 | 40 | 67 | 6.0 | 5.0 | 4.6 | 1.0-5.0 | ± 2 | M3.5-M6.0 | M2.8-M4.9 |
| A8492ABF | 1700 | 1150 | 350 | 50 | 72 | 6.0 | 8.0 | 9.1 | 1.0-7.0 | ± 2 | M3.5-M6.6 | M2.8-M5.7 |
| A8512ABF | 1400 | 1480 | 350 | 50 | 72 | 6.0 | 8.0 | 9.1 | 1.0-8.0 | ± 2 | M3.5-M6.8 | M2.8-M5.9 |
| A8562ABF | 1000 | 1540 | 350 | 50 | 72 | 6.0 | 8.0 | 9.1 | 1.0-9.0 | ± 2 | M4.1-M7.5 | M3.1-M6.2 |
| A8612ABF | 550 | 1570 | 350 | 50 | 72 | 6.0 | 8.0 | 9.1 | 3.0-12.0 | ± 2 | M5.0-M7.8 | M4.0-M6.8 |
| A8662ABF | 300 | 1600 | 350 | 50 | 72 | 6.0 | 8.0 | 9.1 | 3.0-20.0 | ± 2 | M5.0-M9.8 | M4.0-M7.8 |
| A8692ABF | 250 | 1600 | 350 | 50 | 72 | 6.0 | 8.0 | 9.1 | 5.0-28.0 | ± 2 | M6.0-M10.8 | M4.8-M8.6 |
＊ Tool length does not include the air inlet fitting.
▲ Specifications are subject to change without prior notice.
★ 【Customization】Custom specifications are available based on customer requirements. Please contact us for more details.
★ 【Note】Torque values are for reference only. Actual performance may vary depending on operating conditions and environment.
★ 【Note】To ensure component durability and extend tool lifespan, it is recommended that the working torque during use does not exceed 70% of the tool’s maximum torque capacity. Continuous operation at the maximum torque may accelerate component wear and shorten the overall service life of the tool. This guideline can also serve as an important reference when selecting the appropriate model.
● Output Drive
| 1/4" Hex | 5mm | 1/4" Square (FOR 8212~8462 type) |
3/8" Square (FOR 8492~8692 type) |
| ABF | AAF | ABSF | ABSF |
