T-LB Series | Lever Start Type Air Screwdriver.
Model
T10LB,T20LB,T30LB,T35LB,T38LB,T40LB,T45LB,T48LB,T50LB,T55LB,T60LB,T65LB,T68LB
Application
Assembly Line Tools
■ Ultra-Wide Torque Range and Patented Design
Extends the lifespan of motor vanes and reduces tool replacement frequency with its
unique patented structure.
■ Quick-Change Sleeve and External Torque Adjustment
Allows users to rapidly change bits by pulling out the sleeve, while the external torque
design enables convenient one-handed adjustment to boost efficiency.
■ Ergonomic Anti-Slip Design and Patented Clutch
Provides a comfortable grip via ergonomic engineering, paired with a patented staggered-
track clutch system to ensure low torque deviation and high accuracy.
■ Low Noise, Low Vibration, and Color Management
Features a quiet, low-vibration motor alongside a color-coded management system
for effortless torque identification and effective quality control.
| Model | Speed | Weight | Length | Diameter | Air Pressure |
Min Air Hose Bore |
Air Consumption |
Torque Range |
Standard Deviation |
Fastening Capacity | |
| rpm | g | mm | mm | kg/cm² | mm | m³/min | kgf-cm | % | Machine Screw |
Tapping Screw |
|
| T10LB | 1000 | 520 | 210 | 29 | 6.0 | 5.0 | 0.20 | 0.5-2 | ± 3 | M1.4-M2.2 | M1.1-M1.7 |
| T20LB | 1000 | 520 | 210 | 29 | 6.0 | 5.0 | 0.20 | 1-8 | ± 3 | M1.7-M3.4 | M1.4-M2.7 |
| T30LB | 1800 | 520 | 210 | 29 | 6.0 | 5.0 | 0.28 | 3-17 | ± 3 | M2.5-M4.3 | M2.0-M3.4 |
| T35LB | 2200 | 520 | 210 | 29 | 6.0 | 5.0 | 0.28 | 3-20 | ± 3 | M2.5-M4.5 | M2.0-M3.5 |
| T38LB | 1800 | 520 | 210 | 29 | 6.0 | 5.0 | 0.28 | 3-25 | ± 3 | M2.5-M4.8 | M2.0-M3.8 |
| T40LB | 1000 | 520 | 210 | 29 | 6.0 | 5.0 | 0.28 | 5-30 | ± 3 | M2.8-M5.0 | M2.3-M4.1 |
| T45LB | 800 | 520 | 210 | 29 | 6.0 | 5.0 | 0.30 | 8-40 | ± 3 | M3.4-M5.6 | M2.7-M4.5 |
| T48LB | 1700 | 820 | 245 | 37 | 6.0 | 8.0 | 0.55 | 5-45 | ± 3 | M2.8-M5.8 | M2.3-M4.5 |
| T50LB | 1400 | 820 | 245 | 37 | 6.0 | 8.0 | 0.55 | 7-50 | ± 3 | M3.2-M6.0 | M2.6-M4.8 |
| T55LB | 1000 | 820 | 245 | 37 | 6.0 | 8.0 | 0.55 | 7-65 | ± 3 | M3.2-M6.5 | M2.6-M5.2 |
| T60LB | 550 | 820 | 245 | 37 | 6.0 | 8.0 | 0.55 | 15-95 | ± 3 | M4.0-M7.2 | M3.3-M6.0 |
| T65LB | 330 | 840 | 245 | 37 | 6.0 | 8.0 | 0.55 | 30-180 | ± 3 | M5.0-M9.2 | M4.1-M7.1 |
| T68LB | 250 | 840 | 245 | 37 | 6.0 | 8.0 | 0.55 | 50-280 | ± 3 | M6.0-M10.8 | M4.8-M8.6 |
▲ Tool length does not include the air inlet fitting. Specifications are subject to change without prior notice.
★ 【Customization】Custom specifications are available based on customer requirements. Please contact us for more details.
★ 【Note】Torque values are for reference only. Actual performance may vary depending on operating conditions and environment.
★ 【Note】To ensure component durability and extend tool lifespan, it is recommended that the working torque during use does not exceed 70% of the tool’s maximum torque capacity. Continuous operation at the maximum torque may accelerate component wear and shorten the overall service life of the tool. This guideline can also serve as an important reference when selecting the appropriate model.
● Output Drive
| 1/4" Hex | 5mm | 1/4" Square (FOR 10~45 type) |
3/8" Square (FOR 48~68 type) |
| LB | LA | LBS | LBS |
