R-AB Series | Angle Type Air Screwdriver
Model
R10AB,R20AB,R30AB,R35AB,R38AB,R40AB,R45AB,R48AB,R50AB,R55AB,R60AB,R65AB,R68AB
Application
Assembly Line Tools
■ Innovative Quick-Change Bit Design
Allows for simple and effortless bit replacement, significantly boosting overall work efficiency.
■ Patented Clutch System for Extended Lifespan
Ensures precise torque repeatability while effectively extending the service life of the motor vanes.
■ Color-Coded Torque Management System
Combines a professional aesthetic design with precise control for effortless torque identification.
■ Patented Anti-Slip Grip and Streamlined Design
Provides exceptional comfort and enhanced stability during operation through its ergonomic, streamlined structure.
| Model | Speed | Weight | Length | Diameter | Air Pressure |
Min Air Hose Bore |
Air Consumption |
Torque Range |
Standard Deviation |
Fastening Capacity | |
| rpm | g | mm | mm | kg/cm² | mm | m³/min | kgf-cm | % | Machine Screw |
Tapping Screw |
|
| R10AB | 100 | 730 | 225 | 31 | 6.0 | 5.0 | 0.28 | 0.5-2 | ± 5 | M1.4-M2.2 | M1.1-M1.7 |
| R20AB | 1000 | 730 | 225 | 31 | 6.0 | 5.0 | 0.28 | 1.8 | ± 5 | M1.7-M3.4 | M1.4-M2.7 |
| R30AB | 1800 | 730 | 225 | 31 | 6.0 | 5.0 | 0.28 | 3-17 | ± 5 | M2.5-M4.3 | M2.0-M3.4 |
| R35AB | 2200 | 730 | 225 | 31 | 6.0 | 5.0 | 0.28 | 3-20 | ± 5 | M2.5-M4.5 | M2.0-M3.5 |
| R38AB | 1800 | 730 | 225 | 31 | 6.0 | 5.0 | 0.28 | 3-25 | ± 5 | M2.5-M4.8 | M2.0-M3.8 |
| R40AB | 1000 | 730 | 225 | 31 | 6.0 | 5.0 | 0.28 | 5-30 | ± 5 | M2.8-M5.0 | M2.3-M4.1 |
| R45AB | 800 | 730 | 225 | 31 | 6.0 | 5.0 | 0.30 | 8-40 | ± 5 | M3.4-M5.6 | M2.7-M4.5 |
| R48AB | 1700 | 1330 | 315 | 39 | 6.0 | 8.0 | 0.55 | 5-45 | ± 5 | M2.8-M5.8 | M2.3-M4.5 |
| R50AB | 1400 | 1330 | 315 | 39 | 6.0 | 8.0 | 0.55 | 7-50 | ± 5 | M3.2-M6.0 | M2.6-M4.8 |
| R55AB | 1000 | 1330 | 315 | 39 | 6.0 | 8.0 | 0.55 | 7-65 | ± 5 | M3.2-M6.5 | M2.6-M5.2 |
| R60AB | 550 | 1330 | 315 | 39 | 6.0 | 8.0 | 0.55 | 15-95 | ± 5 | M4.0-M7.2 | M3.3-M6.0 |
| R65AB | 330 | 1380 | 315 | 39 | 6.0 | 8.0 | 0.55 | 30-180 | ± 5 | M5.0-M9.2 | M4.1-M7.1 |
| R68AB | 250 | 1380 | 315 | 39 | 6.0 | 8.0 | 0.55 | 50-280 | ± 5 | M6.0-M10.8 | M4.8-M8.6 |
＊ Tool length does not include the air inlet fitting.
▲ Specifications are subject to change without prior notice.
★ 【Customization】Custom specifications are available based on customer requirements. Please contact us for more details.
★ 【Note】Torque values are for reference only. Actual performance may vary depending on operating conditions and environment.
★ 【Note】To ensure component durability and extend tool lifespan, it is recommended that the working torque during use does not exceed 70% of the tool’s maximum torque capacity. Continuous operation at the maximum torque may accelerate component wear and shorten the overall service life of the tool. This guideline can also serve as an important reference when selecting the appropriate model.
● Output Drive
| 1/4" Hex | 5mm | 1/4" Square (FOR 10~45 type) |
3/8" Square (FOR 48~68 type) |
| AB | AA | ABS | ABS |
