A-ABSLL Series | High-Torque Oil-Free Angle Nutrunner - Extra Long Type
Model
A71500ABSLL,A72000ABSLL,A72500ABSLL,A73000ABSLL,A74000ABSLL,A74500ABSLL,A75000ABSLL,A75500ABSLL
Application
Aerospace Industry Tools, Assembly Line Tools
◼ High Torque Performance
Maximum torque reaches up to 160 Nm for demanding industrial applications.
◼ 90° Right-Angle Head & Extra-Long Design
Allows for effortless and flexible operation within confined or narrow workspaces.
◼ Ergonomic Extended Grip
Provides enhanced operator comfort and significantly reduces reaction force during operation.
◼ Vatented MSC Torque Control Technology
Equipped with the 3rd-generation MSC technology and a specialized mechanical design, fully
complying with ISO 5393 Class B (Cpk > 1.67) standards.
| Model | Speed | Weight | Length | Diameter | Noise | Air Pressure |
Min Air Hose Bore |
Air Consumption |
Torque Range |
Square Drive |
Standard Deviation |
Fastening Capacity | |
| rpm | kg | mm | mm | ±dBA | kg/cm² | mm | L/s | Nm | Sq | % | Machine Screw |
Tapping Screw |
|
| A71500ABSLL | 700 | 3.1 | 773 | 34 | 78 | 6.0 | 8.0 | 9 | 6-18 | 3/8” | ± 5 | M6.2-M9.2 | M5.0-M7.1 |
| A72000ABSLL | 430 | 3.1 | 773 | 34 | 78 | 6.0 | 8.0 | 9 | 10-25 | 3/8” | ± 5 | M7.5-M10.0 | M6.0-M8.0 |
| A72500ABSLL | 350 | 3.1 | 753 | 34 | 78 | 6.0 | 8.0 | 9 | 10-28 | 3/8” | ± 5 | M7.5-M10.8 | M6.0-M8.6 |
| A73000ABSLL | 250 | 3.7 | 816 | 42 | 82 | 6.0 | 8.0 | 11 | 10-40 | 1/2” | ± 5 | M7.5-M11.8 | M6.0-M9.4 |
| A74000ABSLL | 180 | 3.7 | 816 | 42 | 82 | 6.0 | 10.0 | 11 | 35-60 | 1/2” | ± 5 | M11.5-M13.2 | M9.0-M10.8 |
| A74500ABSLL | 130 | 4.6 | 820 | 42 | 82 | 6.0 | 10.0 | 11 | 35-70 | 1/2” | ± 5 | M11.5-M14.0 | M9.0-M11.2 |
| A75000ABALL | 100 | 4.6 | 820 | 42 | 82 | 6.0 | 13.0 | 11 | 40-120 | 1/2” | ± 5 | M11.8-M16.8 | M9.4-M13-3 |
| A75500ABSLL | 80 | 4.6 | 820 | 42 | 82 | 6.0 | 13.0 | 11 | 60-160 | 1/2” | ± 5 | M13.2-M18.8 | M10.8-M14.8 |
＊ Tool length does not include the air inlet fitting.
▲ Specifications are subject to change without prior notice.
★ 【Customization】Custom specifications are available based on customer requirements. Please contact us for more details.
★ 【Note】Torque values are for reference only. Actual performance may vary depending on operating conditions and environment.
★ 【Note】To ensure component durability and extend tool lifespan, it is recommended that the working torque during use does not exceed 70% of the tool’s maximum torque capacity.
