A-LBF Series | Straight Oil-Free Low-Reaction Lever-Start Air Screwdriver
Model
A8212LBF,A8362LBF,A8392LBF,A8412LBF,A8462LBF,A8492LBF,A8512LBF,A8562LBF,A8612LBF,A8662LBF,A8692LBF
Application
Aerospace Industry Tools, Assembly Line Tools
■ Quiet, Stable, and Reduced Reaction Force
Ensures a quieter and more stable operation, reducing reaction force by 20% for enhanced user safety and control.
■ Intuitive External Torque Adjustment
Features an external torque adjustment design, making control and setting modifications more intuitive and effortless.
■ Eco-Friendly & High-Efficiency Performance
Designed for environmental sustainability with low energy consumption, while delivering a significant boost in overall performance.
■ Advanced Non-Slip Ergonomic Grip
Equipped with an all-new non-slip grip that is breathable, comfortable, and provides a secure hold, making operations smoother and more effortless.
| Model | Speed | Weight | Length | Diameter | Noise | Air Pressure |
Min Air Hose Bore |
Air Consumption |
Torque Range |
Standard Deviation |
Fastening Capacity | |
| rpm | g | mm | mm | ±dBA | kg/cm² | mm | L/s | Nm | % | Machine Screw |
Tapping Screw |
|
| A8212LBF | 1000 | 640 | 250 | 40 | 67 | 6.0 | 5.0 | 4.6 | 0.1-1.2 | ± 2 | M1.7-M3.7 | M1.5-M3.1 |
| A8362LBF | 2200 | 640 | 250 | 40 | 67 | 6.0 | 5.0 | 4.6 | 0.5-2.5 | ± 2 | M2.2-M4.5 | M1.7-M3.5 |
| A8392LBF | 1800 | 640 | 250 | 40 | 67 | 6.0 | 5.0 | 4.6 | 0.5-3.0 | ± 2 | M2.2-M4.7 | M1.7-M3.8 |
| A8412LBF | 1000 | 640 | 250 | 40 | 67 | 6.0 | 5.0 | 4.6 | 0.5-4.0 | ± 2 | M2.8-M5.0 | M2.2-M4.0 |
| A8462LBF | 800 | 650 | 250 | 40 | 67 | 6.0 | 5.0 | 4.6 | 1.0-5.0 | ± 2 | M3.5-M6.0 | M2.8-M4.9 |
| A8492LBF | 1700 | 950 | 305 | 50 | 72 | 6.0 | 8.0 | 9.1 | 1.0-7.0 | ± 2 | M3.5-M6.6 | M2.8-M5.7 |
| A8512LBF | 1400 | 1050 | 305 | 50 | 72 | 6.0 | 8.0 | 9.1 | 1.0-8.0 | ± 2 | M3.5-M6.8 | M2.8-M5.9 |
| A8562LBF | 1000 | 1110 | 305 | 50 | 72 | 6.0 | 8.0 | 9.1 | 1.0-9.0 | ± 2 | M4.1-M7.5 | M3.1-M6.2 |
| A8612LBF | 550 | 1230 | 305 | 50 | 72 | 6.0 | 8.0 | 9.1 | 3.0-12.0 | ± 2 | M5.0-M7.8 | M4.0-M6.8 |
| A8662LBF | 300 | 1230 | 305 | 50 | 72 | 6.0 | 8.0 | 9.1 | 3.0-20.0 | ± 2 | M5.0-M9.8 | M4.0-M7.8 |
| A8692LBF | 250 | 1250 | 305 | 50 | 72 | 6.0 | 8.0 | 9.1 | 5.0-28.0 | ± 2 | M6.0-M10.8 | M4.8-M8.6 |
＊ Tool length does not include the air inlet fitting.
▲ Specifications are subject to change without prior notice.
★ 【Customization】Custom specifications are available based on customer requirements. Please contact us for more details.
★ 【Note】Torque values are for reference only. Actual performance may vary depending on operating conditions and environment.
★ 【Note】To ensure component durability and extend tool lifespan, it is recommended that the working torque during use does not exceed 70% of the tool’s maximum torque capacity. Continuous operation at the maximum torque may accelerate component wear and shorten the overall service life of the tool. This guideline can also serve as an important reference when selecting the appropriate model.
● Output Drive
| 1/4" Hex | 5mm | 1/4" Square (FOR 8212~8462 type) |
3/8" Square (FOR 8492~8692 type) |
| LBF | LAF | LBSF | LBSF |
