A-BBP Series | Pistol Grip Air Screwdriver (Trigger Start)
Model
A35BBP,A38BBP,A41BBP,A47BBP,A48BBP,A50BBP,A55BBP,A60BBP,A65BBP,A68BBP
Applications
Assembly Line Tools
● Featuring a professional and aesthetic appearance, it combines ergonomics, mechanical engineering, and artistic design, while the dual-color, non-slip grip provides optimal comfort and balance.
● Winner of the 2002 Osaka Good Tool Award, it features an ultra-wide torque range, allowing one tool to replace multiple units and extending the operational lifespan of the motor vanes.
● Equipped with dual top and bottom air intakes, it flexibly adapts to different production line requirements. It is easy to operate and introduces the pioneer ergonomic soft-grip trigger, making screw-driving tasks effortless.
● This tool features an innovative design with a quick-change bit mechanism and low-noise performance. Its ergonomically designed handle is lightweight and comfortable, significantly enhancing operational convenience.
◼ Actuation: Trigger Start
| Model | Speed | Weight | Length | Diameter | Air Pressure |
Min Air Hose Bore |
Air Consumption |
Torque Range |
Standard Deviation |
Fastening Capacity | |
| rpm | g | mm | mm | kg/cm² | mm | m³/min | kgf-cm | % | Machine Screw |
Tapping Screw |
|
| A35BBP | 2200 | 640 | 180 | 33 | 6.0 | 5.0 | 0.28 | 3-20 | ± 3 | M2.5-M4.5 | M2.0-M3.5 |
| A38BBP | 1800 | 640 | 180 | 33 | 6.0 | 5.0 | 0.28 | 3-25 | ± 3 | M2.5-M4.8 | M2.0-M3.8 |
| A41BBP | 1000 | 640 | 180 | 33 | 6.0 | 5.0 | 0.28 | 5-35 | ± 3 | M2.8-M5.0 | M2.3-M4.0 |
| A47BBP | 550 | 640 | 180 | 33 | 6.0 | 5.0 | 0.28 | 10-50 | ± 3 | M3.5-M6.0 | M2.9-M4.8 |
| A48BBP | 1700 | 980 | 215 | 39 | 6.0 | 8.0 | 0.55 | 7-50 | ± 3 | M3.2-M6.0 | M2.6-M4.8 |
| A50BBP | 1400 | 980 | 215 | 39 | 6.0 | 8.0 | 0.55 | 10-60 | ± 3 | M3.5-M6.2 | M2.9-M5.0 |
| A55BBP | 1000 | 980 | 215 | 39 | 6.0 | 8.0 | 0.55 | 12-75 | ± 3 | M3.8-M6.8 | M3.0-M5.5 |
| A60BBP | 550 | 980 | 215 | 39 | 6.0 | 8.0 | 0.55 | 30-110 | ± 3 | M5.0-M7.7 | M4.1-M6.2 |
| A65BBP | 300 | 1100 | 215 | 39 | 6.0 | 8.0 | 0.55 | 30-180 | ± 3 | M5.0-M9.2 | M4.1-M7.1 |
| A68BBP | 250 | 1250 | 215 | 39 | 6.0 | 8.0 | 0.55 | 50-280 | ± 3 | M6.0-M10.8 | M4.8-M8.6 |
▲ Tool length does not include the air inlet fitting. Specifications are subject to change without prior notice.
★ 【Customization】Custom specifications are available based on customer requirements. Please contact us for more details.
★ 【Note】Torque values are for reference only. Actual performance may vary depending on operating conditions and environment.
★ 【Note】To ensure component durability and extend tool lifespan, it is recommended that the working torque during use does not exceed 70% of the tool’s maximum torque capacity. Continuous operation at the maximum torque may accelerate component wear and shorten the overall service life of the tool. This guideline can also serve as an important reference when selecting the appropriate model.
HOT PRODUCTS
-
QF-PBP | Series | Pistol Grip Oil-Free Air Screwdriver (Push-to-Start or Push + Trigger Start
-
