R-PB Series | Push Start Type Air Screwdriver
Model
R10PB,R20PB,R30PB,R35PB,R38PB,R40PB,R45PB,R48PP,R50PB,R55PB,R60PB,R65PB,R68PB
Product Application
Assembly Line Tools
■ Color-Coded Torque Management System
Boosts quality control efficiency across production lines through clear and easy-to-identify color coding.
■ Quick-Change Bit System with Ergonomic Engineering
Integrates a rapid-change bit mechanism with an ergonomic structure, ensuring effortless and smooth operation.
■ Precision Clutch System and Anti-Slip Grip
Combines a high-precision clutch system with a non-slip handle to deliver exceptional operator comfort and superior tool control.
■ Multi-Patented Design with Wide Torque Range
Features an ultra-wide torque capacity driven by multiple patented designs, effectively extending the overall service life of the tool.
| Model | Speed | Weight | Length | Diameter | Air Pressure |
Min Air Hose Bore |
Air Consumption |
Torque Range |
Standard Deviation |
Fastening Capacity | |
| rpm | g | mm | mm | kg/cm² | mm | m³/min | kgf-cm | % | Machine Screw |
Tapping Screw |
|
| R10PB | 1000 | 500 | 210 | 29 | 6.0 | 5.0 | 0.20 | 0.5-2 | ± 3 | M1.4-M2.2 | M1.1-M1.7 |
| R20PB | 1000 | 500 | 210 | 29 | 6.0 | 5.0 | 0.20 | 1-8 | ± 3 | M1.7-M3.4 | M1.4-M2.7 |
| R30PB | 1800 | 500 | 210 | 29 | 6.0 | 5.0 | 0.28 | 3-17 | ± 3 | M2.5-M4.3 | M2.0-M3.4 |
| R35PB | 2200 | 500 | 210 | 29 | 6.0 | 5.0 | 0.28 | 3-20 | ± 3 | M2.5-M4.5 | M2.0-M3.5 |
| R38PB | 1800 | 500 | 210 | 29 | 6.0 | 5.0 | 0.28 | 3-25 | ± 3 | M2.5-M4.8 | M2.0-M3.8 |
| R40PB | 1000 | 500 | 210 | 29 | 6.0 | 5.0 | 0.28 | 5-30 | ± 3 | M2.8-M5.0 | M2.3-M4.1 |
| R45PB | 800 | 500 | 210 | 29 | 6.0 | 5.0 | 0.30 | 8-40 | ± 3 | M3.4-M5.6 | M2.7-M4.5 |
| R48PB | 1700 | 825 | 245 | 37 | 6.0 | 8.0 | 0.55 | 5-45 | ± 3 | M2.8-M5.8 | M2.3-M4.5 |
| R50PB | 1400 | 825 | 245 | 37 | 6.0 | 8.0 | 0.55 | 7-50 | ± 3 | M3.2-M6.0 | M2.6-M4.8 |
| R55PB | 1000 | 825 | 245 | 37 | 6.0 | 8.0 | 0.55 | 7-65 | ± 3 | M3.2-M6.5 | M2.6-M5.2 |
| R60PB | 550 | 825 | 245 | 37 | 6.0 | 8.0 | 0.55 | 15-95 | ± 3 | M4.0-M7.2 | M3.3-M6.0 |
| R65PB | 330 | 920 | 245 | 37 | 6.0 | 8.0 | 0.55 | 30-180 | ± 3 | M5.0-M9.2 | M4.1-M7.1 |
| R68PB | 250 | 920 | 245 | 37 | 6.0 | 8.0 | 0.55 | 50-280 | ± 3 | M6.0-M10.8 | M4.8-M8.6 |
＊ Tool length does not include the air inlet fitting.
▲ Specifications are subject to change without prior notice.
★ 【Customization】Custom specifications are available based on customer requirements. Please contact us for more details.
★ 【Note】Torque values are for reference only. Actual performance may vary depending on operating conditions and environment.
★ 【Note】To ensure component durability and extend tool lifespan, it is recommended that the working torque during use does not exceed 70% of the tool’s maximum torque capacity. Continuous operation at the maximum torque may accelerate component wear and shorten the overall service life of the tool. This guideline can also serve as an important reference when selecting the appropriate model.
● Output Drive
| 1/4" Hex | 5mm | 1/4" Square (FOR 10~45 type) |
3/8" Square (FOR 48~68 type) |
| PB | PA | PBS | PBS |
